    Max. Working Pressure 14 bar Central Air Conditioning Water Pressure Differential Switch

    Ask Lasest Price
    Brand Name : IVANPER
    Model Number : DPS100A
    Price : $70.00 - $85.00/units
    • Product Details
    • Company Profile

    Max. Working Pressure 14 bar Central Air Conditioning Water Pressure Differential Switch

    Product Description
    Max. Working Pressure 14 bar Central Air Conditioning Water Pressure Differential Switch
    Specification
    model
    DPS100A
    Maximum voltage
    250VAC
    Maximum current
    3A
    Output
    Normally open or normally closed (SPDT)
    DP differential pressure set value / return difference
    10~100kPa
    DP hysteresis
    3~7kPa
    Maximum allowable static pressure
    14 bar
    Maximum allowable pressure difference
    14 bar
    Working medium
    Oil / water / air (other media please specify when ordering)
    Operating temperature
    -20℃~93℃
    Setpoint repeatability deviation
    ±1%
    Enclosure rating
    IP54
    Connector
    1/4” SAE(7/16”-20UNF)
    Max. Working Pressure 14 bar Central Air Conditioning Water Pressure Differential Switch
    Max. Working Pressure 14 bar Central Air Conditioning Water Pressure Differential Switch
    DPS series adjustable differential pressure switch can be used in oil, water and air fluid engineering to detect the pressure
    difference of filters, pumps, heat exchangers, chillers and coils. When the pressure difference (flow rate) in the system rises or falls When the set value is reached, an alarm is output or an alarm of the cut-off function is provided to the automatic control system. It can also be used to indicate the status of the pump or filter. The differential pressure switch with adjustable set point can be directly calibrated by the factory according to customer requirements, and the calibration value is printed on the product label, and the user does not need to make adjustments on site. Customers can calibrate through professional instruments according to the pressure difference required by the equipment.
    .
    Max. Working Pressure 14 bar Central Air Conditioning Water Pressure Differential Switch
    Max. Working Pressure 14 bar Central Air Conditioning Water Pressure Differential Switch
    Max. Working Pressure 14 bar Central Air Conditioning Water Pressure Differential Switch
    The differential pressure switch with adjustable set point is installed at the inlet and outlet of the heat exchanger of the central air conditioning chiller. It can be used to detect the water flow of the heat exchanger. It is an accurate flow control method. It is based on the resistance and flow of the HVAC equipment. The curve design, we know that the heat exchanger, water filter, water pump and valve of HVAC equipment have performance curves of resistance and flow. We detect the difference between the inlet and outlet water pressure at both ends of the device and set it in advance with the device. The fixed value is compared to accurately control the flow. As a flow control switch, it has the characteristics of accurate flow control, no additional resistance to the system, no requirements on the pipe diameter and no disturbance of water flow disturbance. It can replace any form of target flow switch as the flow control of HVAC water system. Compared with the target type flow switch, it can avoid the false flow caused by the pump cavitation (the actual flow rate is large, but the water is mixed with air and the actual flow rate is not large), so it can be widely used in the use of brazed plate heat exchangers, casing Large and medium-sized air-cooled or water-cooled chillers with heat exchangers and shell-and-tube heat exchangers are used for water flow protection of the condenser and evaporator and also have the function of partial antifreeze protection..
