    Air Adjustable Differential Pressure Transmitter with IP 65 Protection and LCD Display

    Ask Lasest Price
    Brand Name : IVAN
    Supply Ability : 1000 Piece/Pieces per Week
    Price : $120.00/pieces 2-99 pieces
    • Product Details
    • Company Profile

    Air Adjustable Differential Pressure Transmitter with IP 65 Protection and LCD Display

    Air Adjustable Differential Pressure Transmitter with IP 65 Protection and LCD Display
    Product Description
    Product Description

    Differential pressure transmitter


    PT-DP014 series differential pressure transmitters are used for building automation in the HVAC/R industry , pressure and flow monitoring, and low differential pressure test in industry application.

    Air Adjustable Differential Pressure Transmitter with IP 65 Protection and LCD Display
    Detailed Images
    Detailed Images

    LCD display.

    Sho more clarity.

    International CE certification.

    safe and secure.

    Pressure input interface.

    Stainless steel material, strong and durable.

    Internal circuit
    Internal circuit
    Air Adjustable Differential Pressure Transmitter with IP 65 Protection and LCD Display
    Product Parameter
    Product Parameter
    Model
    PT-DP014
    Media
    Air and neutral gas
    Pressure range
    -100Pa~0Kpa~100Pa...10Kpa
    Simulate range
    0~10000Pa
    Accuracy
    0.5%F.S,1%F.S
    Power supply
    16~30VDC
    Output signal
    4 ~ 20 mA , 0 ~ 10 Vdc,0~5Vdc
    Operating TEMP
    -10~+60°C
    Compensate range
    -10~+70 ℃
    Pressure connection
    metal barb connection,Ø 6.2 mm
    Cable connection
    max diameter: Ø 8 mm
    Display
    LCD display,50 x 22.5 mm
    Protection grade
    IP65
    Unidirectional pressure
    Bidirectional pressure
    0~100Pa
    0~±50Pa
    0~250Pa
    0~±100Pa
    0~500Pa
    0~±250Pa
    0~1000Pa
    0~±500Pa
    0~2500Pa
    0~±1000Pa
    0~5000Pa
    0~±2500Pa
    0~10000Pa
    0~±5000Pa
    Product display
    Product display
    Air Adjustable Differential Pressure Transmitter with IP 65 Protection and LCD Display
    Air Adjustable Differential Pressure Transmitter with IP 65 Protection and LCD Display
    Air Adjustable Differential Pressure Transmitter with IP 65 Protection and LCD Display
    Air Adjustable Differential Pressure Transmitter with IP 65 Protection and LCD Display
