    4" 120mm Mini Gas or Air Type Differential Pressure Gauge 0 60Pa ±2% FS Accuracy at 21C

    Ask Lasest Price
    Brand Name : IVANPER
    Model Number : A2000
    Supply Ability : 10000 Piece/Pieces per Month
    Price : $28.00/units 5-49 units
    • Product Details
    • Company Profile

    4" 120mm Mini Gas or Air Type Differential Pressure Gauge 0 60Pa ±2% FS Accuracy at 21C

    Product Description
    4" (120mm)Mini Gas or Air Type Differential Pressure Gauge 0-60Pa
    4" 120mm Mini Gas or Air Type Differential Pressure Gauge 0 60Pa ±2% FS Accuracy at 21C
    Brand Name:

    J&H
    Rated pressure::

    68~103Kpa
    Item:
    Differential Pressure Gauge
    Overpressure::
    172KPa
    Type::

    120mm
    Supply Ability:
    10000 Piece/Pieces per Month
    4" 120mm Mini Gas or Air Type Differential Pressure Gauge 0 60Pa ±2% FS Accuracy at 21C
    Direction for use
    使用说明
    he Air conditioning differential pressure gauge used to measure fan and blower pressure, filter resistance, wind speed, furnace
    pressure, orifice plate differential pressure, bubbles water level and liquid amplifier or hydraulic system pressure. It using
    frictionless magnetic components, can rapidly measure the micro-pressure air or non-corrosive gases, including positive, negative
    (vacuum) or differential. No wear, hysteresis and clearance. Not filling, vaporization and freezing. This design has
    anti-vibration, anti-shake and high overpressure capability, you can guarantee access to high precision.

    • Specification:
    1) Medium: air and non-combustible, compatible gases (optional gas)
    2 )Housing: cast aluminum housing or ABS shell, glass beveled panels. Dark gray coating, can withstand 168 hours salt spray test
    3) Accuracy: 2% FS (mm units, and the range with the corresponding pa)
    4) Pressure range:. -20Hg To 15 psig (-0.677 bar to 1.034 bar) 5) Temperature range: 20 to 140 ° F (-6.67 to 60 ° C) 6 )Hole size: 114mm 7) Mounting Orientation: Diaphragm in vertical 8) Connections: same 1/8 "NPT high and low pressure fittings, one pair on the side, one pair in the back 9) Weight: 500g / only
    4" 120mm Mini Gas or Air Type Differential Pressure Gauge 0 60Pa ±2% FS Accuracy at 21C
    Company Introduction
    Ivanpeng specializes in operating pressure, temperature and humidity, wind speed, liquid level, flow and other intelligent instruments and sensors in stable and reliable operation in the industrial site. Each instrument has standard signal output and high stability. Wind speed, temperature and humidity and 2000 series micro differential pressure meters have been used as GMP standard products in the biological pharmaceutical and food industry.
    Range
    0-30PA, ± 30PA,0-60PA, ± 60PA, 0-100PA, 0-125PA, 0-250PA, 0-300PA,
    0-500PA,0-750PA,0-1KPA,0-1.5KPA,0-2KPA,0-2.5KPA,0-3KPA,0-5KPA,0-10KPA
    Measured media
    Non-corrosive gas or air

    4" 120mm Mini Gas or Air Type Differential Pressure Gauge 0 60Pa ±2% FS Accuracy at 21C
    4" 120mm Mini Gas or Air Type Differential Pressure Gauge 0 60Pa ±2% FS Accuracy at 21C
    4" 120mm Mini Gas or Air Type Differential Pressure Gauge 0 60Pa ±2% FS Accuracy at 21C

    Our Services & Strength

    Ivanpeng company has a relatively complete product line, the products involve high-tech industrial automation process instruments such as pressure, temperature, humidity, flow, level, water quality analysis, testing instruments, etc.; the business fields cover HVAC, biopharmaceutical, machinery manufacturing, power electronics, petrochemical, aerospace, shipbuilding, automobile and other industries. The company has a relatively complete R & D platform, product manufacturing platform, product sales and after-sales service platform BeijingAiFanpengInstrumentCo.,Ltd.
