    24VDC Power Supply Miniature Wind Speed Sensor with 14mm Probe Diameter 4-20mA Transmitter

    Ask Lasest Price
    Brand Name : IVAN
    Model Number : AF410C
    Supply Ability : 1000 Unit/Units per Week
    Price : $93.00/units 10-99 units
    • Product Details
    • Company Profile

    24VDC Power Supply Miniature Wind Speed Sensor with 14mm Probe Diameter 4-20mA Transmitter

    China makes miniature wind speed sensors
    Product Description


    AF410C2 mini air velocity transmitters were developed to obtain accurate measuring results over a wide range of velocity and temperature. A high-quality hot film sensor element based on cutting- edge thin film technology ensures maximum sensitivity, even at lowest mass flows. AF410C2 can be used to the narrow space and measure very low velocity .For HVAC, Ventilation, Air-condition, Purification, Lab, Purification Workshop..
    Specifications
    Power Supply
    24V DC/AC
    Measure Range
    0-5m/s 0-10m/s 0-15m/s 0-20m/s 0-30m/s
    Output
    0-10V 4-20mA Rs485{modbus-RTU}
    Measure Accuracy
    ±{0.2m/s +3%of MV}
    Consumption
    2.5W
    Protection Rating
    IP65
    Response Latency
    0.2 s
    Resolution
    0.01m/s
    Sensing Elements
    Thermal film sensor
    Working Environment
    Temperature: -20-85ºC Humidity:5%-95%
    Probe Length
    Installation of flange :150mm / Customization
    Material of Probe
    ABS Engineering plastic
    24VDC Power Supply Miniature Wind Speed Sensor with 14mm Probe Diameter 4-20mA Transmitter
    24VDC Power Supply Miniature Wind Speed Sensor with 14mm Probe Diameter 4-20mA Transmitter
    24VDC Power Supply Miniature Wind Speed Sensor with 14mm Probe Diameter 4-20mA Transmitter
    24VDC Power Supply Miniature Wind Speed Sensor with 14mm Probe Diameter 4-20mA Transmitter
    24VDC Power Supply Miniature Wind Speed Sensor with 14mm Probe Diameter 4-20mA Transmitter
    Recommend Products
    Packing & Delivery
    24VDC Power Supply Miniature Wind Speed Sensor with 14mm Probe Diameter 4-20mA Transmitter
    24VDC Power Supply Miniature Wind Speed Sensor with 14mm Probe Diameter 4-20mA Transmitter
    Company Profile

    Beijing Ifpen Instrument EnterpriseWas founded in 2011, adjacent to the beautiful political and cultural center, located in Daxing Industrial Development Zone, Beijing.The company has a professional, innovative technica team and standardized production team. Over the years, we have been committed to the research and development of industrial instrument production, focusing on the research and development of the field of"wind speed and air volume", and achieving zero breakthrough of turbulence jump. Since its establishment, the company insists on"innovation, quality, integrity" to serve the new and old customers. Ivan products not only occupy a high proportion of market share in China, as a national brand, go abroad, exported to the world.
    24VDC Power Supply Miniature Wind Speed Sensor with 14mm Probe Diameter 4-20mA Transmitter
    Exhibition
    24VDC Power Supply Miniature Wind Speed Sensor with 14mm Probe Diameter 4-20mA Transmitter
    Certifications
    24VDC Power Supply Miniature Wind Speed Sensor with 14mm Probe Diameter 4-20mA Transmitter
    24VDC Power Supply Miniature Wind Speed Sensor with 14mm Probe Diameter 4-20mA Transmitter
    FAQ
    FAQ for better and easy cooperation:
    1.Why choose IVAN?
    We are the leading manufactuer, OEM & ODM service areoffered
    2.How about the sample of IVAN product?
    We could send you the samples but the freight and the sample are charged.
    4.How about IVAN payment term?
    TT &L/C &Westem Union(40% deposit, the balance before shipment)
    5.How about BIOBASE delivery time?
    Within 7-15 workdays after receving deposit
    6.How about IVAN validity of quotation?
    Usualy 30 days as the shipping freight and exchange rate can be fluctuant.
    7.What is the shipping port?
    FOB to Qingdao Port, China(also can ship according to customers' request)
    8.How about the package?
    Bubble film+ Coton +Standard export wooden case.
    9.How to inspect the goods?
    Products i be checked by our QC staffist then our proejct manager. Cient can come and check bythemselves or third party check is available.
    Any quesion or help pease felfre t contact with any time!
