    Medium Temp 0-60C Micro Differential Pressure Meter Featuring 1/8" ID Tubing Connection

    Ask Lasest Price
    Brand Name : IVANPER
    Model Number : F3S3
    Supply Ability : 10000 Piece/Pieces per Month
    Price : $110.00 - $150.00/units
    • Product Details
    • Company Profile

    Medium Temp 0-60C Micro Differential Pressure Meter Featuring 1/8" ID Tubing Connection

    Product Description
    Applications and features
    Adopt high-precision MEMS sensor and digital technology to detect positive pressure, negative pressure or differential pressure.
    It can be widely used to measure the pressure of fans and blowers, filter resistance, wind speed, pressure drop caused by furnace ventilation and orifice plate, liquid level of foaming system and pressure of supercharger or hydraulic system
    It can be used to monitor blood and respiratory pressure on medical equipment
    Applicable to embedded installation, plane installation and other installation methods
    A variety of ranges, output modes and units are optional
    No moving parts, anti vibration
    At the same time, it has super large and super bright nixie tube display and optional arc-shaped LED indication of analog
    mechanical meter
    Two groups of relay output or alarm can be selected, and LED indication is provided at the same time
    accuracy up to ± 1% FS, optional ± 0.5% FS
    Key functions: zero calibration, unit switching, relay setting, response time setting, range / signal calibration, etc
    Technical index
    Medium: air and non flammable, non corrosive gas, not sensitive to moisture / dust / condensation / oil pollution
    Medium temperature: 0-60 ° C
    Shell: cast aluminum shell, PC panel
    Working environment: - 20-85 ° C
    Temperature compensation: 0-50 ° C
    Working pressure: 1, 2, 5kpa, depending on the range;
    Overload 5xfs, failure pressure 10xfs
    Dimension: see dimension drawing
    Process connection: 1 / 8 "tapered nozzle, two pairs in total (side or back)
    Display: 4-digit 0.8 "nixie tube, highlighted in red
    Analog output: 0-10V / 4-20mA (three wire)
    Output load: ≤ 500 Ω (current type), ≥ 2K Ω (voltage type)
    Communication output: RS485 / MODBUS (9600-n-8-2)
    Relay output: 2 × SPST, 1A / 30VDC, 0.5a/125vac
    Accuracy: ± 1.0% FS, optional ± 0.5% FS
    Long term stability: ± 0.5% FS / year
    Temperature drift coefficient: < 0.05% FS / ° C
    Response time: 0.5-30s
    Power supply: 15-28v AC or 15-36v DC
    Keys: 3 touch keys
    Protection grade: IP65
    Weight: About 340g
